What are white pages?
White pages can be written on any subject about any thing that may be scientific or relate to engineering.
The subject in this case is racing and in particular racing on a dirt oval track. These white pages touch mostly on the use of a Stock Car chassis for racing. Such stock cars are frame based cars with a solid rear axle and a wishbone front suspension with unequal control arms which retain a steering spindle attached top and bottom.
These cars are "pure stock", "street stock"
and "pro stock".
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
The race shop...
Without going out of our way we must establish a
set of basic tools that you will need to build your racecar. There is no reason
why you cannot build a contender out of your basement garage. It does not
require a large shop with a lift or an oversized compressor, but there are some
unconventional items that you will need to build a decent chassis if you wish to
compete.
There is a white
page file on this server that you can read.
The basic requirements for a home garage are a small medium HP air compressor, a
220 VAC outlet for a 150 AMP MIG welder, and at least 30 AMPS of 110 VAC for
power tools.
The tools you will want can be most any set of good wrenches, ratchet sets, hand
tools (screw drivers) and of course hammers and pliers. You know what these
tools are, and you probably have a decent set already. A set of AN wrenches and
a torque wrench will be handy.
The special tools are where you will spend your
money. You will want a set of racing scales and a set of toe plates. You will
need a caster-camber gauge, and a quality set of taps and dies. If you have the
room, you will need a sheet metal brake and some kind of a press. Don't forget
the engine stand and a basic tire machine.
One, 1/2 inch drill press will be required.
The shop layout is not important, but you will need a parts inventory so try to
keep that separated from the shop interior.
Import your equipment list
Download a CSV template with one click
Import your equipment/device list to be commissioned with a click
Dynamic type-ahead search to find specific equipment/devices
Batch-assign device types and system IDs to your equipment
Your body system will require
a learning curve...
I have uploaded a well documented "street stock" body build "white page".
This was modified from
an earlier article written by Jeff Hunneycutt from a Hot Rod magazine article
[PDF].
The requirements to build must first conform to
your track rules, however meeting these rules is not always possible. So we show
you some tricks and offer a few tips along the way.
You need an aluminum sheet metal brake. The shortest brake you can use to build
this body will be 72" wide or six foot and must be capable of bending 2.5 MM
material. The sheets of aluminum that are used today are 10 foot by 4 foot and
1.5 MM (0.60) thick.
A standard Street Stock door panel will require a single sheet, 72 inches long
by 38 inches wide. The
extra long width allows for double folds top and bottom for strength. Generally,
you will need eight
sheets of aluminum to complete a basic stock car body.
For a Novice, there are three choices:
Pure Stock, Charger or Hornet Stock...
The choice begins at your track. The promoter runs at least one entry level class. These are support
classes. They reinforce the headliners and intermediates. These could be Sprint Cars, Late Models or Modified racecars. All of these come in various configurations.
SUPPORT DIVISIONS run after the headliners. Your "stock car" will run late in the show, or it may run
last each week. That is up to the promoter.
He may give you a chance to headline for a special event.
You will have to choose your class based upon your budget and your driver experience. Let me help
you decide...build safety first. No matter what else you do, consider your life depends on what you
fabricate. I don't like "hornets" (basic uni-body junk).
Yes, four cylinder racecars or compact trucks
(with frames) are fine and can be a lot of fun; "cheap shit" uni-body cars are "dead" dangerous.
Frame chassis racecars can be built strong and reasonably safe. You should never depend on the
body to protect you!! Build the car as if your life depended on it...
Be smart, choose a V8 Pure Stock or Compact Truck 4 or 6 cylinder with a frame chassis.
If your local track does not run these classes, look elsewhere to race (period)
GM Metric chassis design criteria.
Roll your own or purchase a rolling "G"
body stock race car such as a Monte Carlo, or Cutlass.
There are a few of these remaining and many are in decent condition. You don't
care about anyhting but the chassis. Is it rust free, is it straight, has it
been badly abused??
The GM metric chassis is a solid axle rear driven car, with an unequal control arm imdependent
front suspension. These make ideal dirt track stock cars.
c2r1
The Street Stock chassis...
View your most important metric chassis features here.
There is a White Page section dedicated to builders and building
for yourself. The DIY concept is unique and I will walk you
through the hardest parts. I will help you decide, roll your
own or buy a chassis cage kit.
The "roll cage" kits are available on-line. The most popular
comes from CSC Racing. Canadian Stock Car a division of
Bicknell Racing. They have a basic cage kit model 1502 that
is the perfect foundation of a quality GM metric chassis. All
Star performance makes a starter kit for "pure stock" racers
and is reasonable in price.
You can install this kit into your frame using a modern 150A MIG welder.
It will become the basic foundation for your "pure stock" entry level racecar.
You can build a safe car around this cage. You will add bars front and rear.
I will show you how in the actual "white page" available here.
Here is the basic kit. This will be centered over your stock GM metric chassis and located along the L/R rails.
